100 Gallon per day
6 Stage Reverse Osmosis Water System with De-Ionized unit.
And 4.4 Gallon Tank
Designed for the Marine Aquarium enthusiast.
ASSEMBLED IN USA
With clear housings for easy Maintenance
This
unit is our top of the line system for those of us that want VERY pure
water, we designed it for the marine aquarium keeper because they need
VERY pure water to make there fish healthy and happy. Why shouldn't you
take advantage of that technology and have the purest water available
for your family. Most bottled water is
filtered the same way.
-
We have been building custom Reverse Osmosis systems since 1994, most for the marine fish enthusiast
-
Clear Housings make it easier to maintain
-
4.4 Gallons Storage Tank the largest on ebay.
-
100 GPD TFC Reverse Osmosis Membrane faster refresh rate and longer lasting.
-
IN Line DI filter for the cleanest water
-
All parts are NSF and or FDA Approved
-
Made in USA
We
use only the best components available and custom build them to your
order, in our shop in California.
Clear housing for easy maintenance. Allows you to see the condition of the pre filters.
High Capacity 25-Micron Pre filter Removes the larger partials (25 millionths of an inch and larger).
High Capacity 10-Micron Coconut Carbon Block with Housing removes medium partials and chlorine. Makes the water taste better.
High
Capacity 1-Micron Pre filter for the cleanest water available into the
membrane. This removes the maxim junk from the water and does not have
carbon to leach in and clog the membrane.
100 Gallon per day AUTO FLUSH RO Membrane with the RO Housing.
Our larger filter gives you faster refresh rate and longer life.
High Capacity 11" In-Line Filter (DI)
High Capacity 11" In-Line Filter (Carbon)
Exclusive Stainless Steel Top 4.4 gallon Pressurize Water Tank with ball valve.
Auto shutoff valve
Needle piercing fresh water feed clamp for quick and easy installation
Saddle clamp for the discharge water
Lead free long reach faucet
Filter Wrench for tightening and removing the housings
FDA approved food grade tubing 12 Feet of extra tubing for easy filling of containers
Stainless
steel Check Valve : This part is crucial to the operation of the unit
as it prevent the RO water from moving back into the membrane and keeps
the auto shut off stable
Instruction Manual
How Reverse Osmosis Systems Work:
Reverse
Osmosis systems purify water by passing it through a series of filters
to remove large contaminants and harmful chemicals/pollutants and then
by forcing it through a special plastic membrane to remove very small
contaminants. In the filtration stage, tap or well water first passes
through sediment filters where silt, sediment and particles (like sand
and clay) are removed. Water is then forced through a high efficiency
carbon block filter where micro-pulverized carbon efficiently adsorbs chlorine, chloramines, pesticides and
other harmful organic chemicals and pollutants. The pre-filtered water,
now stripped of membrane-damaging particles and chemicals, flows into
the RO membrane module where pure water molecules are forced through the
RO membrane leaving salts, metals, and other impurities to be flushed from the system.
How De ionization Works
Reverse
Osmosis membranes, although very good at removing contaminants, still
allow trace amounts to pass through. Nitrates, phosphates and silica are
among these substances not fully removed. By further processing RO
water through multi-layered, mixed-bed de ionization cartridges, even
those difficult to remove chemicals are reduced to virtually
undetectable levels. The De ionization cartridge contains resin beds of
positive ions (cations) and negative ions (anions) which react with
contaminants to chemically remove them from the water stream. The result
is ultra-pure water that is extremely low in contaminants.
Nominal Rejection Characteristics of Thin Film Composite Reverse Osmosis Membranes
|
Ion |
% Rejection*
|
|
Calcium |
99
|
|
Sodium |
98
|
|
Magnesium |
98
|
|
Potassium |
96
|
|
Manganese |
98
|
|
Iron |
98
|
|
Aluminum |
98
|
|
Copper |
99
|
|
Nickel |
99
|
|
Cadmium |
97
|
|
Silver |
96
|
|
Zinc |
98
|
|
Mercury |
97
|
|
Hardness Ca&Mg |
97
|
|
Radioactivity |
97
|
|
Chloride |
98
|
|
Ammonium |
90
|
|
|
Ion |
% Rejection* |
|
Bromide |
95
|
|
Phosphate |
98
|
|
Cyanide |
97
|
|
Sulfate |
99
|
|
Thiosulfate |
98
|
|
Silicate |
95
|
|
Silica |
98
|
|
Nitrate |
95
|
|
Boron |
70
|
|
Borate |
50
|
|
Fluoride |
95
|
|
Polyphosphate |
98
|
|
Orthophosphate |
98
|
|
Chromate |
95
|
|
Bacteria |
99+
|
|
Lead |
98
|
|
Arsenic |
90
|
|
|
